DSC/DV MCP
|
|
|
|
|
DSC/DV MCP
|
|
ChipSiP has cultivated in providing DSC/DV MCP solution for years. Slim , small and higher resolution DSC/DV are mainstream products now. In addition, more functions like GPS, motion picture and continuous shooting will be integrated into DSC/DV. How to design all functions into smaller PCB needs the technology of integration. ChipSiP provides variety of MCP products to satisfy this requirement.
|
|
Products
|
|
一，CT42 : NOR + SDRAM
|
|
1.RQ.=Request
2.Core-Chip: Ralink RT3050, Ralink RT3052
|
|
Part Number |
Description |
FLASH |
DRAM/RAM |
Package |
Outline
(mm) |
Status |
|
Voltage |
Bus Width |
Speed |
Voltage |
Bus Width |
Speed |
|
CT42320TB566C1 |
32Mb NOR Flash (Top Boot)+256Mb SDRAM |
3.3V |
x8/x16 |
70ns |
3.3V |
x16 |
166MHz |
FBGA |
10x13x1.4 |
Ready |
|
CT42640TB566C1 |
64Mb NOR Flash (Top Boot)+256Mb SDRAM |
3.3V |
x8/x16 |
70ns |
3.3V |
x16 |
166MHz |
FBGA |
10x13x1.4 |
2011Q1 |
|
|
|
|
二，CT47 : NAND + DDR SDRAM
|
|
1.RQ.=Request
2.Core-Chip: ZORAN: Coach 8/9、Novatek: 96433
|
|
Part Number |
Description |
FLASH |
DRAM/RAM |
Package |
Outline
(mm) |
Status |
|
Voltage |
Bus Width |
Speed |
Voltage |
Bus Width |
Speed |
|
CT47568SR566A |
256Mb NAND + 256Mb DDR SDRAM |
3.3V |
x8 |
50ns |
2.5V |
x16 |
DDR400 |
TFBGA |
10x13x1.4 |
RQ. |
|
|
|
|
三，CT48 : NAND + DDRII SDRAM
1.RQ.=Request
2.Core-Chip: ZORAN: Coach 10/11/12、Novatek: 96433/96450,T1: DM350、Fujitsu: M4B/4ML/M5B/M6A、Ambarella: A2s/A5
|
|
Part Number |
Description |
FLASH |
DRAM/RAM |
Package |
Outline
(mm) |
Status |
|
Voltage |
Bus Width |
Speed |
Voltage |
Bus Width |
Speed |
|
CT48568SR246C |
256Mb NAND+1Gb DDRII SDRAM |
3.3V |
x8 |
50ns |
1.8V |
x16 |
DDRII800 |
TFBGA |
10x13x1.2 |
MP |
|
CT48128NS246C |
512Mb NAND+1Gb DDRII SDRAM |
3.3V |
x8 |
30ns |
1.8V |
x16 |
DDRII800 |
TFBGA |
10x13x1.2 |
MP |
|
CT48248NS246C |
1Gb NAND+1Gb DDRII SDRAM |
3.3V |
x8 |
25ns |
1.8V |
x16 |
DDRII800 |
TFBGA |
10x13x1.2 |
MP |
|
CT48248NS486C |
1Gb NAND+2Gb DDRII SDRAM |
3.3V |
x8 |
25ns |
1.8V |
x16 |
DDRII800 |
TFBGA |
10x13x1.4 |
2011Q1 |
|
CT48568SR126A |
256Mb NAND+512Mb DDRII SDRAM |
3.3V |
x8 |
50ns |
1.8V |
x16 |
DDRII667 |
TFBGA |
9x9x1.2 |
MP |
|
CT48128NS246A |
512Mb NAND+1Gb DDRII SDRAM |
3.3V |
x8 |
50ns |
1.8V |
x16 |
DDRII667 |
TFBGA |
9x9x1.2 |
MP |
|
CT48568SR248A |
256Mb NAND+1Gb DDRII SDRAM |
3.3V |
x8 |
50ns |
1.8V |
x16 |
DDRII667 |
TFBGA |
9x9x1.2 |
2011Q1 |
|
CT48248NS126A |
1Gb NAND+512Mb DDRII SDRAM |
3.3V |
x8 |
25ns |
1.8V |
x16 |
DDRII667 |
TFBGA |
9x9x1.2 |
MP |
|
CT48248NS246A |
1Gb NAND+1Gb DDRII SDRAM |
3.3V |
x8 |
25ns |
1.8V |
x16 |
DDRII800 |
TFBGA |
9x9x1.2 |
MP |
|
CT48248NS246F |
1Gb NAND+1Gb DDRII SDRAM |
3.3V |
x8 |
25ns |
1.8V |
x16 |
DDRII800 |
TFBGA |
15x15x0.9 |
MP |
|
|
|
|
四，CT83 : DDRII SDRAM stack
1.RQ.=Request
2.Core-Chip:DDRII stack (1Gb/2Gb follow JEDEC standard)
|
|
Part Number |
Description |
FLASH |
DRAM/RAM |
Package |
Outline
(mm) |
Status |
|
Voltage |
Bus Width |
Speed |
Voltage |
Bus Width |
Speed |
|
CT83242D |
1Gb DDRII |
|
|
|
1.8V |
x32 |
667/800Mbps |
FBGA,128Balls |
10.5x13.5x1.1 |
MP |
|
CT83482D |
2Gb DDRII |
|
|
|
1.8V |
x32 |
667/800Mbps |
FBGA,128Balls |
10.5x13.5x1.1 |
MP |
|
CT83962C |
4Gb DDRII |
|
|
|
1.8V |
x32 |
667/800Mbps |
FBGA,137Balls |
10x13x1.4 |
MP |
|
CT83486C |
2Gb DDRII |
|
|
|
1.8V |
x16 |
667/800Mbps |
FBGA,128Balls |
10x13 |
2011Q1 |
|
CT83966C |
4Gb DDRII |
|
|
|
1.8V |
x16 |
667/800Mbps |
FBGA,128Balls |
10x13 |
2011Q3 |
|
|
|
|
|
|
|
|
|
|
